BASIC SERIES
The machines in the BASIC line consist of numerically controlled tube bending machines with completely automatic cycles. They feature small bending heads so they can even run a single processing cycle to produce tube geometries that normally require a double bending direction, leading to notable advantages in terms of both productivity and precision.
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
170
Max. Bending Speed
400
Max.Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
No. Cnc Axes
3
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
170
Max. Bending Speed
240
Max.Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
No. Cnc Axes
4
Key features
Al, Cu, Ot Max. Tube Dia.
100X0.6
Bending Direction
Right Or Left
Mains Frequency
50
Max. Bending Radius
600
Max. Bending Speed
36
Max.Od For Hitch Feeding
100
Mild Steel Max. Od (R=350-450 N/Mm²)
100X2.5
