HEAVY-S SERIES
Complex processes are no problem for Heavy series endforming machines with vertical clamping. The line guarantees high quality standards and precision, and ensures high production levels. These large machines can complete up to six steps during the cycle, with precise movements of the two CNC axes. The machine is managed by the CNC Siemens 840D sl: very high performance numerical control technology. These compact endforming machines were designed for easier operation and tool changes, and to take up less physical space, which is remarkable for a machine large enough to process large diameters.
Key features
Clamp Force
196
Clamp Length
80
Cnc Model
Siemens Sinumerik 840D Sl
Deformation Force
157-177
Dimensions L X W X H
1970X1975x1940
Forming Speed
4100
Max Deformation Length
250
Key features
Clamp Force
20
Clamp Length
80
Cnc Model
Siemens 840D Sl
Deformation Force
16
Dimensions L X W X H
4800X2400x1975
Forming Speed
4100
Hydroforming
Integrated
Key features
Clamp Force
392
Clamp Length
120
Cnc Model
Siemens 840D Sl
Deformation Force
245
Dimensions L X W X H
3600X4000x3310
Forming Speed
4400
Max Deformation Length
300
Key features
Clamp Force
883
Clamp Length
160
Cnc Model
Siemens 840D Sl
Deformation Force
588
Dimensions L X W X H
3520X3840x2475
Forming Speed
1310
Max Deformation Length
500
