UP&DOWN SERIES
Tube bending machines in the Up&Down series feature a double bending direction that makes it possible to use only one machine, without operator intervention, to complete tube geometries that usually require post processing operations. This provides considerable advantages for both productivity and precision. The movements of these tube bending machines can turn the tube in the space during the process, eliminating interference with the machine or with the geometry of the part being produced. The nine controlled axes that govern the movement of Up&Down are driven by absolute digital electric motors with Full Electric technology and controlled by a CNC Siemens 840D sl.
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
300
Max. Od For Hitch Feeding
33
Mild Steel Max. Od (R=350-450 N/Mm²)
22X2
No. Cnc Axes
10
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
300
Max. Od For Hitch Feeding
33
Mild Steel Max. Od (R=350-450 N/Mm²)
25X3
No. Cnc Axes
10
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
260
Max. Od For Hitch Feeding
37
Mild Steel Max. Od (R=350-450 N/Mm²)
32X2.5
No. Cnc Axes
10
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
240
Max.Od For Hitch Feeding
37
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
No. Cnc Axes
10
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
250
Max. Bending Speed
150
Max.Od For Hitch Feeding
62
Mild Steel Max. Od (R=350-450 N/Mm²)
55X2.5
Key features
Bending Direction
Right And Left
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
240
Max.Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
