LINEAR SERIES
Tube bending machines from the Linear series have small bending heads that allow them to create particularly complex geometries in a single work cycle. These machines can form multistack and multiradius bends with manually reconfigurable bending direction, and can made bends with CLR/DIA ratio even less than 0.8. The nine controlled axes that govern the machine’s movement are driven by absolute digital electric motors with Full Electric technology and controlled by a CNC Siemens 840D sl.
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
300
Max. Od For Hitch Feeding
33
Mild Steel Max. Od (R=350-450 N/Mm²)
25X3
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
300
Max. Od For Hitch Feeding
33
Mild Steel Max. Od (R=350-450 N/Mm²)
25X3
No. Cnc Axes
9
Key features
Bending Direction
No Info On Website
Mains Frequency
50
Max. Bending Radius
170
Max. Bending Speed
240
Max. Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
32X2
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
170
Max. Bending Speed
330
Max. Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
32X2
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Height Between Bending Planes
210/290
Mains Frequency
50
Max. Bending Radius
150
Max. Bending Speed
330
Max. Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
Key features
Bending Direction
?
Mains Frequency
50
Max. Bending Radius
170
Max. Bending Speed
330
Max. Od For Hitch Feeding
42
Mild Steel Max. Od (R=350-450 N/Mm²)
42X2
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
250
Max. Bending Speed
150
Max. Od For Hitch Feeding
60
Mild Steel Max. Od (R=350-450 N/Mm²)
55X2.5
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
250
Max. Bending Speed
130
Max. Od For Hitch Feeding
81
Mild Steel Max. Od (R=350-450 N/Mm²)
63X3
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left (Reconfigurable)
Mains Frequency
50
Max. Bending Radius
250
Max. Bending Speed
93
Max. Od For Hitch Feeding
81
Mild Steel Max. Od (R=350-450 N/Mm²)
80X2
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left
Mains Frequency
50
Max. Bending Radius
400
Max. Bending Speed
66
Max.Od For Hitch Feeding
90
Mild Steel Max. Od (R=350-450 N/Mm²)
114X2.5
No. Cnc Axes
9
Key features
Bending Direction
Right Or Left
Mains Frequency
50
Max. Bending Radius
450
Max. Bending Speed
36
Max. Od For Hitch Feeding
123
Mild Steel Max. Od (R=350-450 N/Mm²)
150X3
No. Cnc Axes
9
